10KG Low Budget Motorized Cable Unwinder

JCW-WP04

Small wires AWG 18 - AWG 26

Max 10 KG wire roll

Smooth acceleration & deceleration

Two-way drive, clockwise & anti-clock

Automatic induction with independent brakes

Inquire Now

Cable Roll Pay-off

JCW-WP04 10KG Load Motorized Cable Unwinder

Useful wire prefeeder, ultra-cheap

The JCW-WP04 motorized cable unwinder is a useful wire dereeler for small wires ranging from AWG 18 to AWG 26, this lightweight equipment is ideal for tension-free prefeeding to an automatic wire and cable processing machine.

This cable dereeler is equipped with a two-way drive, which is activated with a rotation dancer pendulum arm, the feed speed automatically adjusts to the actual requirement of any wire and cable processing machine, including the cutting machine, cutting and stripping machine, automatic terminal crimping machine, etc.

When ordering wire prefeeding machines, we recommend customers submit cable samples or images, also the cutting length and wire processing machine models, so as to offer the most proper models to meet your processing needs.

Model	JCW-WP04 Economic Motorized Cable Unwinder
Wire range	AWG 18 - AWG 26
Wire roll weight	10 KG
Power supply	AC 110 - 220V, 50 / 60 Hz
Dimensions	L 390 x W 390 x H 500 mm
Weight	7 KG
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
