Compact design, space-saving
Servo-motorized system, highly automatic
Touch screen, user-friendly interface, simple operation
Fully programmable, fast switch conductor cross-section and width
JCW-TS203
Compact design, space-saving
Servo-motorized system, highly automatic
Touch screen, user-friendly interface, simple operation
Fully programmable, fast switch conductor cross-section and width
Model | JCW-TS203 Ultrasonic Wire Welding Machine |
Work frequency | 20 kHz |
Rated power | 3000 W |
Cross section area | 2 ~ 20 mm², copper & aluminum |
HMI | 7" color touch screen |
Cycle time | approx 0.7 seconds, depends on wire sizes |
Welder lifetime | 100,000 times welding |
Power supply | AC 220V ± 10%, 50 / 60 Hz |
Air supply | 0.3 - 0.6 MPa ( clean and dry air ) |
Dimensions | L 640 x W 420 x H 300 mm |
Weight | 55 KG |
CE-Conformity | Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
