High-end 5 Wires Terminal Crimping to Tinning Machine

JCW-CST21

High-level automatic wire processing machine, process 5 wires simultaneously

Cutter adopts double guide rails and precision grinding screw

Air inhale and jet, collect waste rubber and keep the machine clean

4 cylinders drive the twisting unit to create the perfect twisting effect.

Parallel move on the front end, ensure stable crimping

Inquire Now

High-level 5 Wires Crimping to Tinning Machine

Model	JCW-CST21 High-end 5 Wires Crimping to Tinning Machine
Wire range	AWG 32 - AWG 16
Raw material	PVC, Teflon, Low halogen, etc.
Cutting length ( L )	42 - 1000 mm [ Other lengths on request ]
Cutting length tolerance	0.002 x L
Stripping length	Front side: Max 9.5 mm [ Customizable ]
Stripping length	Rear side: Max 13.5 mm [ Customizable ]
Twisting length	2 - 10.5 mm [ Customizable ]
Tinning length	0.5 - 13.5 mm
Production rate	5500 - 6500 pcs/h by 300mm cutting length
Data library	100 programs
Detector	Terminal run-out, Wire run-out, Wire knot, Terminal crimping, Air pressure, Heating
Optional peripherals	CFM, Wire unwinder, Conveyor belt
Display	10" touch screen, English / Chinese [ other languages on request ]
Power supply	AC 220V ± 10%, 50 / 60 Hz [ 110V on request ]
Rated power	2300 W
Air supply	0.5 - 0.8 MPa [ Clean and dry air ]
Weight	600 KG
Dimensions	L 2000 x W 1070 x H 1900 mm
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
