Servo motorized rotary stripping machine
Equipped 4 pcs of high-quality cutting blades & 2 pcs of stripping blades
Fully programmable, saving 99 recipes
Precise cutting & stripping, 0,01mm increment
JCW-S800
Servo motorized rotary stripping machine
Equipped 4 pcs of high-quality cutting blades & 2 pcs of stripping blades
Fully programmable, saving 99 recipes
Precise cutting & stripping, 0,01mm increment
HV Cable Stripping Machine
Model | JCW-S800 High Voltage EV Shielded Cable Rotary Stripping Machine |
Cable diameter | 3 - 30 mm [ optional φ22mm, 120mm² ] |
Cutting depth increment | 0.01 mm |
Stripping length ( L ) | 1 - 800 mm [ full stripping until 500mm ] |
Stripping length increment | 0.01 mm |
Multi-step stripping | 9 |
Rated power | 2500 W |
Rotary cut blade | 4 pcs |
Stripping blade | 2 pcs |
Recipe library | 99 |
Display | 7" color touchscreen, English / Chinese [ other languages on request ] |
Power supply | AC 110 - 220 V ± 10%, 50 / 60 Hz |
Dimensions | L 1050 x W 520 x H 1650 mm |
Weight | 215 KG |
CE-Conformity | Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
