Heavy-duty semi-auto cable stripping machine
Powerful rotate cutter head
Straight insulation cutting, perfect stripping
Standard version reaches 1000mm stripping length
Other stripping lengths can be customized
JCW-S1000
Heavy-duty semi-auto cable stripping machine
Powerful rotate cutter head
Straight insulation cutting, perfect stripping
Standard version reaches 1000mm stripping length
Other stripping lengths can be customized
Heavy-duty Cable Stripping Machine
Model | JCW-S1000 Cable Rotate Stripping Machine |
Cable diameter | 15 - 44 mm [ Customizable ] |
Cutting depth increment | 0.01 mm [ Customizable ] |
Stripping layers | 2 |
Stripping length | 1000 mm |
Recipe | 100 |
Rated power | 2000 W |
Display | 4.3" color touchscreen, English / Chinese [ other languages on request ] |
Blade | 4 pcs, Tungsten |
OEM | Yes |
Air supply | 0.5 - 0.7 MPa ( clean and dry air ) |
Power supply | AC 110 - 220 V ± 10%, 50 / 60 Hz |
Dimensions | L 1680 x W 680 x H 1300 mm |
Weigh3t | 80 KG |
CE-Conformity | Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
